TOP > Connectors > Nanaboshi Electric Mfg.

Nanaboshi Electric Mfg.

Nanaboshi Electric Mfg. Circular Metal Connectors.

Various Nanaboshi Electric Mfg. Circular metal Connectors.

Metal connectors for indoor use: NCS, NJC, NR, NET, etc. Waterproof metal connectors for outdoor use: NWPC, NJW, NRW, NEW, NHVC, etc. Waterproof Ethernet Connector for outdoor: ENJW series, ENRW series

Stocks include the highly versatile NCS series of metal connectors (plugs) for indoor use, as well as the NJC series of up to 24 pins, the one-touch lock type NR series, the NWPC series of water-resistant outdoor connectors, the NJW series, NRW series, ENJW series, ENRW series, etc. (excluding certain sizes).

Various Circular Metal Connectors.

NCS series

Nanaboshi Electric Mfg. ncs

Standard metal connectors

Available for a variety of use in panels and industrial equipment, from power supply to signals.

For the NCS series, we carry shell size 16 (contacts:2–3) to 60 (64) (contacts:2–40).
We also carry stocks in all sizes of regular contacts and reversed contacts (excluding some).

NCS series price list

NJC series

Nanaboshi Electric Mfg. njc

Diverse products that cater to control equipment, measuring equipment, medical equipment, and to a variety of other purposes including power supply.

Shell sizes 16–32, contacts: 2–37
Stocks in all sizes of regular contacts and reversed contacts (excluding some).
Crimp-type contacts available.

NJC series price list

NR series

Nanaboshi Electric Mfg. nr

One touch lock type metal connector

One-touch type metal connectors for various purposes such as control equipment, measuring equipment, etc.

Shell sizes 20 (contacts: 2–14), Shell sizes 24 (contacts: 2–24)
Stocks in all sizes of regular contacts and reversed contacts (excluding some).
Crimp-type contacts available.

NR series price list

NET series

Nanaboshi Electric Mfg. net

Metal connectors with earth protection circuits.
Compliant with European safety standards.

Shell sizes 20-28, contacts: 3–8
Protection circuit structure: earth contact of sequence structure (prioritized connection) that connects with metal shells.

NET series price list

High-voltage connectors

NHVC series

Nanaboshi Electric Mfg. nhvc

This outdoor waterproof connector can batch connect 3.3 kV and 6.6 kV 3-phase high-voltage cables.

These connectors have proven themselves in plant equipment, emergency power supply equipment, outdoor transmission equipment, large electric construction equipment, inspection instruments, and other devices under extreme weather conditions.

NHVC series price list

Waterproof connectors

NWPC series

Nanaboshi Electric Mfg. nwpc

Standard waterproof metal connectors

Waterproof metal connectors that cater to various purposes such as construction equipment, etc.

Water resistance: No trace of water exposure after being submerged 5 cm under water for 24 hours, in its normal state of use.

Shell size 16 (contacts:2–3) to 60 (64) (contacts:2–40).
We also carry stocks in all sizes of regular contacts and reversed contacts (excluding some).

NWPC series price list

NJW series

Nanaboshi Electric Mfg. njw

A variety of Waterproof connectors that cater to control equipment, measuring equipment, and various purposes including power supply.

Waterproof metal connectors designed to be water resistant when connected.
Water resistance: No trace of water exposure after being left under water pressure of 40 kPca for 24 hours, in its normal state of use.

Shell size 16-32, contacts:2–37.
We also carry stocks in all sizes of regular contacts and reversed contacts (excluding some).

NJW series price list

NRW series

Nanaboshi Electric Mfg. nrw

One-touch lock Waterproof connectors that cater to various purposes such as control equipment, measuring equipment, etc.

High-intensity plastic, superior in weather resistance and shock resistance, adopted for shells.

Shell size 20 (contacts:2–14), Shell size 24 (contacts:2–24), Shell size 28 (contacts:16–37).
We also carry stocks in all sizes of regular contacts and reversed contacts (excluding some).

NRW series price list

NAW series

Nanaboshi Electric Mfg. naw

NAW is most suitable for outdoor measuring equipment, a construction machine,etc.

  • Water-proof metal connectors
  • Quick coupling and locking structure
  • RoHS directive
  • UL, CSA standard (Size 20)
  • Cable termination : Soldering

Shell size 16 (contacts:3,5,8), Shell size 20 (contacts:2–14), Shell size 24 (contacts:2–24).

NAW series price list

NEW series

Nanaboshi Electric Mfg. new

Waterproof Metal connectors with earth protection circuits.
Compliant with European safety standards.

A variety of Waterproof connectors that cater to control equipment, measuring equipment, and various purposes including power supply.

Shell size 20 (contacts:3), Shell size 24 (contacts:3,4), Shell size 28 (contacts:4,8).
We also carry stocks in all sizes of regular contacts and reversed contacts (excluding some).

NEW series price list

ENJW/ENRW series

Nanaboshi Electric Mfg. ENJW/ENRW

Waterproof Ethernet Connector for outdoor

  • Modular plug connection at rear of receptacle and inside of adaptor.
  • Transmission Property : Cat 5e
  • Compatible with STP cable.
  • Excellent in waterproofness and weather-resistance, and best suited for outdoor applications
  • Available in both screw and single-push locking system.
  • NJW and NRW shells which have been proven in various outdoor application have been adopted.
  • JJ adaptor built-in receptacle ・adaptor

We also carry stocks in ENJW and ENRW.

ENJW/ENRW series price list

UL and CSA standardized acquisition connectors

General purpose type : NJC NR NET
Waterproof type : NJW NRW NEW

Series Shell size Number of contacts Rating of electricity Rating of Voltage
5A 10A 15A 20A
NJC
NJW
16 3 125V
5
NJC
NR
NJW
NRW
20 2 250V
3
4
5
7
10
12
NJC
NJW
NRW
24 2
3
4
5
10
14
16
NET
NEW
24 3
4
NJC
NJW
NRW
28 16
24
NET
NEW
28 4
8

EN (European Norm) standardized acquisition connectors

NET NJC NR : Protection degree IP4X
NEW NRW : Protection degree IP47

Series Shell size Number of contacts Rating of electricity Rating of Voltage
10A 15A 20A 30A
NJC 20 2 250V
3
4
24 2
3
4
5
32 3
4
NR 20 2
3
4
24 2
3
4
5
NRW 20 2
3
4
5
24 2
3
4
5
NET
NRW
24 3
4
28 4
8
NET
NRW
32 3
4

As the sole agent for Nanaboshi Electric Mfg. Co., Ltd., we carry the largest stock of their products from NCS, NJC, NR, NET series mentioned above, as well as water-resistant connector series such as NWPC, NJW, NRW, etc. and are able to respond to requests for quick delivery.
